Pixel pitch: 3mm

• Pixel 3mm
• LED array SMD2020
• Brightness 1000 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 192mm(W) x 192mm(H)
• Cabinet size 576mm x576mm
• Cabinet weight 8kg
• Maintenance front & back

Pixel pitch: 3.9mm

• Pixel 3.91mm
• LED array SMD2020
• Brightness 1200 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 250mm(W) x 250mm(H)
• Cabinet size 500mm x 500mm
• Cabinet weight 8kg
• Maintenance front & back

Pixel pitch: 4mm

• Pixel 4mm
• LED array SMD2020
• Brightness 1000 nits
• Refresh 1920Hz/ 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 256mm(W) x 128mm(H)
• Cabinet size 512mm x512mm
• Cabinet weight 7kg
• Maintenance front & back

Pixel pitch: 4.8mm

• Pixel 4.81mm
• LED array SMD2020
• Brightness 1000 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 250mm(W) x 250mm(H)
• Cabinet size 500mm x 500mm / 500mm x 1000mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 5mm

• Pixel 5mm
• LED array SMD2121 / SMD3528
• Brightness 1500 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 160mm(W) x 160mm(H) / 320mm x 160mm(H)
• Cabinet size 640mm x 640mm / 960mm x 960mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 5.95mm

• Pixel 5.95mm
• LED array SMD2121 / SMD3528
• Brightness 1500 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 250mm(W) x 250mm(H)
• Cabinet size 500mm x 500mm / 500mm x 1000mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 6mm

• Pixel 6mm
• LED array SMD2121 / SMD3528
• Brightness 1500 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 192mm(W) x 96mm(H) / 192mm(W) x 96mm(W)
• Cabinet size 640mm x 640mm / 960mm x 960mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 7.62mm

• Pixel 7.62mm
• LED array SMD2121 / SMD3528
• Brightness 1500 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 140°/ 140° （50% brightness）
• Module size 244mm(W) x 122mm(H) / 244mm x 122mm(H)
• Cabinet size 732mm x 732mm / 976mm x 976mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 8.9mm

• Pixel 8.9mm
• LED array SMD3528
• Brightness 1200 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 120°/ 120° （50% brightness）
• Module size 250mm(W) x 250mm(H)
• Cabinet size 500mm x 1000mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 10mm

• Pixel 10mm
• LED array SMD3528
• Brightness 1000 nits
• Refresh 1920Hz / 3840Hz
• Viewing angle 120°/ 120° （50% brightness）
• Module size 320mm(W) x 160mm(H)
• Cabinet size 960mm x 960mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 2.97mm

• Pixel 2.97mm
• LED array SMD2020 black led
• Brightness 1200 nits
• Refresh 1920Hz
• Viewing angle 160°/ 160° （50% brightness）
• Module size 250mm(W) x 250mm(H)
• Cabinet size 500mm x 500mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 2.5mm

• Pixel 2.5mm
• LED array SMD2020 black led
• Brightness 1000 nits
• Refresh 1920Hz
• Viewing angle 160°/ 160° （50% brightness）
• Module size 160mm(W) x 160mm(H)
• Cabinet size 480mm x 480mm
• Cabinet weight
• Maintenance front & back

Pixel pitch: 1.92mm

• Pixel 1.923mm
• LED array SMD1010 black led
• Brightness 1000 nits
• Refresh 1920Hz
• Viewing angle 160°/ 160° （50% brightness）
• Module size 200mm(W) x 150mm(H)
• Cabinet size 400mm x 300mm
• Cabinet weight
• Maintenance front maintenance

Pixel pitch: 1.667mm

• Pixel 1.667mm
• LED array SMD1010 black led
• Brightness 1000 nits
• Refresh 2000Hz
• Viewing angle 160°/ 160° （50% brightness)
• Module size 200mm(W) x 150mm(H)
• Cabinet size 400mm x 300mm
• Cabinet weight -
• Maintenance front maintenance
